Caltta DH560U Digital Hand Portable


In Stock

RRP: From £215.00 ex. VAT

£215.00 From £215.00

Don’t see an option available, or an item is out of stock? Get in touch: 01633 270005

Please specify programming requirements at checkout

Unsure of licence requirements, or programming configuration – our team can help

Is hiring a better option for you?


Basic purchase cost includes:

01 x Caltta DH560U hand portable, 01 x antenna, 01 x battery, 01 x belt clip

Item description:


The Caltta DH560 UHF portable radio is a rugged IP67 waterproof radio with display, offering a long battery life with its standard 2500mAH battery. The radio as standard has an emergency button and lone worker safety features which are only normally found on higher-tier radios from some other manufacturers.

Supports DMR Tier2
Provides high quality voice service. It responses the call of professional users anywhere and anytime.

Support 2 Slots in DMO and Roaming
DH560 can support 2 slots in DMO that double the Capacity of communication. And it also supports roaming in IP repeaters’ network.

Loud and Clear Sound
With carefully optimised audio design, combined excellent audio encoder, it provides loud and clear sound.

Large Capacity Battery
With 2500mAh battery and optimised power consumption of DMR, battery life is long enough for professional communication.

Excellent Man-Machine Interface Design
Based on professional user habits, simple MMI is developed,which helps the professional users to operate radio more comfortably.

Abundant Configuration
DH560 supports emergency button and lone worker.

Higher Safety
The DMR standard provides higher safety and reliability for voice and data than analogue standard.

Reliable Quality
Meets IP67 standard, and is suitable for outdoor work. Shock, vibration, solar radiation and other indexes meet Mil-STD-810 G. It qualifies for all kinds of severe working environments.

Specific Product codes:

2000000001494 : DH500U UHF 400-470MHZ 4W display

Download brochure

*Optional feature licence

Digital Protocol ETSI TS 102 361-1,-2,-3
Frequency UHF 400-470MHZ 4W, VHF: 136-174MHz
Channel Capacity 32
Zone Capacity 2
Channel Spacing 12.5kHz/20KHz/25KHz
Frequency Stability ±0.5ppm
Operating Voltage 7.4V
Battery Capacity 2500mAh
Battery Life(5:5:90) Analogue: 16 hours
Digital: 20 hours
Size (H×W×D) 116.4×54.5×36.5mm (Without Antenna)
Weight About 275g (With Antenna and Battery)
Vocoder AMBE++
Emergency button Standard
Lone Worker Standard
Encryption Basic Standard – Advanced Encryption (*feature licence key)
Accessories Delivery
